The Kollmorgen S20360-SRS is a high-performance servo drive designed for precision motion control applications in industrial automation systems. As part of Kollmorgen’s S200 series, this advanced drive delivers exceptional torque control with a compact footprint, making it ideal for space-constrained installations. The S20360-SRS features 360V AC input and 20A continuous current output, enabling precise control of servo motors up to 7.5kW.
Engineered for seamless integration, the Kollmorgen S20360-SRS supports multiple feedback interfaces including absolute encoders and resolvers. Its modular architecture allows flexible configuration for various motor types while maintaining industry-leading power density.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | S20360-SRS |
| Manufacturer | Kollmorgen |
| Type | Digital Servo Drive |
| Input Voltage | 3-phase 360V AC ±10% |
| Output Current | 20A continuous (40A peak) |
| Control Bandwidth | 2.5kHz |
| Feedback Interfaces | EnDat 2.2, Hiperface DSL, Resolver |
| Communication Protocols | EtherCAT, PROFINET, CANopen |
| Protection Class | IP65 (front panel) |
| Operating Temp | 0°C to +55°C |
| Dimensions | 215×150×60mm |
| Weight | 2.1kg |
Key Features and Advantages:
Precision control: The Kollmorgen S20360-SRS achieves ±1 arc-minute positioning accuracy through advanced compensation algorithms. Its adaptive filter technology suppresses mechanical resonance.
System integration: Native support for industrial networks simplifies connection to PLC and CNC controllers. Automatic motor identification reduces commissioning time.
Reliability: Reinforced power components ensure stable operation in 24/7 production environments. Conformal coating protects against contaminants.
Application Areas:
- Machine Tools: High-speed spindle control
- Robotics: Multi-axis articulated arms
- Packaging: Precision web handling
- Semiconductor: Wafer positioning stages
In automated assembly lines, the Kollmorgen S20360-SRS enables synchronized multi-axis coordination with <5μs jitter.
Related Products:
- S20120-SRS: Lower power variant (120V/10A)
- S20500-SRS: Higher power version (500V/30A)
- S20360-DN: Dual-axis configuration
- S20360-PM: Permanent magnet motor edition
- S20360-LN: Liquid-cooled model
Installation and Maintenance:
Installation preparation: Verify proper ventilation clearance (min. 50mm) before mounting S20360-SRS. Use shielded cables for all signal connections.
Maintenance recommendations: Perform annual thermal imaging inspection of power terminals. Clean cooling fins quarterly in dusty environments.
Product Assurance:
Kollmorgen provides 36-month warranty with global technical support for S20360-SRS. Each unit undergoes 200-hour validation testing including vibration and thermal cycling.
