The Kollmorgen CR06200-000000 is a high-performance digital servo drive designed for precision motion control in demanding industrial automation applications. As part of Kollmorgen’s S7000 series, this advanced drive delivers exceptional torque control with industry-leading dynamic response. The CR06200-000000 features 240V AC input and 20A continuous current output, making it ideal for CNC machinery and robotics applications.
Engineered for maximum flexibility, the Kollmorgen CR06200-000000 supports multiple feedback interfaces including absolute encoders and resolvers. Its compact design allows for easy integration in space-constrained control cabinets while maintaining excellent thermal performance.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | CR06200-000000 |
| Manufacturer | Kollmorgen |
| Type | Digital Servo Drive |
| Input Voltage | 3-phase 240V AC ±10% |
| Output Current | 20A continuous (40A peak) |
| Control Bandwidth | 2.8kHz |
| Feedback Interfaces | EnDat 2.2, Hiperface DSL, Resolver |
| Communication Protocols | EtherCAT, PROFINET, CANopen |
| Protection Class | IP65 |
| Operating Temperature | -10°C to +55°C |
| Dimensions | 220×155×60mm |
| Weight | 2.3kg |
Key Features and Advantages:
Precision control: The Kollmorgen CR06200-000000 achieves micron-level positioning accuracy through advanced motion control algorithms. Its adaptive vibration suppression technology eliminates mechanical resonance for smoother operation.
System integration: Native support for industrial networks simplifies connection to PLC and motion controllers. Automatic motor parameter identification reduces commissioning time significantly.
Reliability: Robust power components ensure stable operation in 24/7 production environments. Advanced thermal management extends product lifespan.
Application Areas:
- Machine Tools: High-speed machining centers
- Robotics: Articulated arm assembly systems
- Packaging: High-speed labeling machines
- Semiconductor: Precision wafer handling
In automated production lines, the Kollmorgen CR06200-000000 enables synchronized multi-axis coordination with minimal jitter.
Related Products:
- Kollmorgen S20360-SRS high-performance servo driver
- Kollmorgen S72402-NANANA Digital servo drive
- S72404-NANANA: Dual-axis configuration
- ABB PPD 517 A3011 3BHE041576R3011 excitation controller
- Kollmorgen S70602-NANANA Digital Servo driver
Installation and Maintenance:
Installation preparation: Ensure proper ventilation clearance (minimum 80mm) before mounting CR06200-000000. Use only high-quality shielded cables for all signal connections.
Maintenance recommendations: Perform bi-annual thermal inspection of power terminals. Clean cooling fins regularly in dusty environments to maintain optimal performance.
Product Assurance:
Kollmorgen provides 12-month warranty with global technical support for CR06200-000000. Each unit undergoes rigorous 400-hour validation testing including thermal cycling and vibration tests to ensure reliability.
