The ABB 5SHX0660F0001 3BHL000386P0101 represents cutting-edge power electronics technology, combining high-voltage handling capabilities with precision switching performance. As part of ABB’s renowned HiPak IGBT module series, this 5SHX0660F0001 3BHL000386P0101 model features a 3300V/600A rating with integrated NTC temperature sensor and press-pack housing design. The module’s asymmetric blocking configuration makes it ideal for voltage source converters in HVDC applications, achieving 99.2% efficiency at 1kHz switching frequency. With its patented “StakPak” packaging technology, the ABB 5SHX0660F0001 delivers 40% higher power density than conventional modules while maintaining mechanical stability under 50kN contact force.
Technical Specifications
Product Model | 5SHX0660F0001 3BHL000386P0101
Manufacturer | ABB
Product Type | IGBT Module
Voltage Rating | 3300V VCES
Current Rating | 600A IC (25°C)
Switching Frequency | 1kHz (max)
Power Dissipation | 2400W (max)
Thermal Resistance | 0.035K/W (junction-case)
Gate Drive Voltage | ±15V (recommended)
Isolation Voltage | 6000V AC (1min)
Module Weight | 450g
Operating Temperature | -40°C to +125°C
Certifications | UL, CE, RoHS
Key Features and Advantages:
The ABB 5SHX0660F0001 3BHL000386P0101 introduces revolutionary emitter-controlled IGBT technology that reduces turn-off losses by 30% compared to conventional designs. Its integrated pressure contact system eliminates bond wire failures, achieving 10× longer lifetime in cycling applications. The module’s low-inductance design (<15nH) minimizes voltage overshoot during fast switching (dv/dt up to 10kV/μs), while the built-in NTC sensor enables precise junction temperature monitoring (±3°C accuracy).
Advanced features include short-circuit withstand capability of 10μs at 125°C junction temperature, making the 5SHX0660F0001 3BHL000386P0101 exceptionally robust in fault conditions. The aluminum nitride (AlN) ceramic substrate provides superior thermal conductivity (180W/mK) while maintaining electrical isolation integrity. For harsh environments, the module’s hermetically sealed housing resists humidity and corrosive gases per IEC 60721-3-4 Class 4C2.
Application Fields:
In HVDC transmission systems, the 5SHX0660F0001 3BHL000386P0101 serves as the core component in modular multilevel converters (MMC), handling 300MW power blocks with <0.5% THD. Industrial drives leverage its 100kA asymmetric short-circuit capacity for steel mill rolling stands, while renewable energy applications benefit from the module’s 150% overload capability during wind gust conditions in 10MW wind turbine converters.
The module’s press-pack design makes it particularly suitable for railway traction inverters where vibration resistance (>5g) is critical. Mining applications utilize its -40°C cold-start capability in electric shovel drives, while the integrated temperature monitoring enables predictive maintenance in offshore oil platform VFDs.
Related Products:
- 5SHX0660F0002 – Higher current version (800A) with same footprint
- 5SHY3545L0002 – 4500V/3500A variant for ultra-high power applications
- 5SNA2400E330300 – Snubber capacitor kit optimized for this module
- 5STP03D4200 – Press-pack diode module for companion use
- 5SXE10-0181 – Gate driver board with fiber optic interface
Installation and Maintenance:
Installation preparation: The 5SHX0660F0001 3BHL000386P0101 requires mounting torque of 5.5Nm±10% on all screws. Use thermal grease with conductivity >3W/mK and apply 0.1mm uniform layer.
Maintenance recommendations: Perform annual thermal imaging inspection of busbar connections. Measure gate-emitter leakage current every 24 months using ABB’s GT1000 tester. For 5SHX0660F0001 modules in dusty environments, clean cooling surfaces quarterly using isopropyl alcohol.
Product Assurance:
All ABB 5SHX0660F0001 3BHL000386P0101 modules include 12-month warranty covering manufacturing defects.
